8 inch Wafer UV Light Curing Machine reduce the adhesive strength of all UV-sensitive dicing tapes under controlled environment.
Parameters:
Mode | DSXUV-DG-8 | Glass | Quartz glass |
Cooling | Air cooling | Irradiation | From top down |
Luminous | Mercury lamp (full band) | Power | 1-4KW |
Lighting area | 110*320mm | Intensity | UVA>200mW/cm2 |
Uniformity | 90% | Mercury lamp | 2KW*220V*L400mm |
Voltage | 220V | Operation mode | Motor drive (track slide scan) |
Run number | Adjustable (touch screen) | Running speed | Adjustable (touch screen) |
Mercury Lamp UV Tape UV Curing System Characteristics:
1.Table type, chain drive
2.Adjustable time and brightness, touch screen operation, simple and convenient
3.Compatible, large size iron rings are compatible with small size
4.Uniformly reduce the viscosity of UV film
5.Fast curing in few seconds
6.Intuitive control panel
7.Enable time control process
8.Compact design
9.Compliance with the highest safety standards
10.Environmentally friendly
Application for UV Tape UV Curing Systems:
Suitable for semiconductor material like optical lens, LED, IC, semiconductor, integrated circuit board, mobile hard disk, etc., reducing UV film viscosity like glass filter, UV tape, blue film.
